Shanghai Pudong International Airport Seawall Phase I, Section III Project

Project Name	Shanghai Pudong International Airport Seawall Phase I, Section III Project
Project Location	Shanghai, China	Engineering Costs	42.08 million yuan
Start time	October, 1998	Completion time	December, 1999
Company	Name
Owner	Shanghai Pudong International Airport Company
Design	Shanghai Water Engineering Design and Research Institute
Supervisory	Shanghai Hongbo Engineering Supervision Co., Ltd.
Project Overview
Pudong International Airport is facing the sea to the east. In order to reduce the occupation of farmland, the second phase of the runway expansion by reclaiming land from the sea is all formed by the reclamation. The phase I of the project is divided into three sections, with a total length of 6 kilometers. The design standard for the levee is a 200 year return period plus a 12 level typhoon. The levee body is constructed using mud filled pipe bags, with a bottom width of 90 meters, a top width of 8 meters, and a height of 9 meters. The seaward side is equipped with grouted block stones and a wave barrier plate protective structure. The top of the levee is paved with asphalt, and the inner slope is covered with green grass.
